PROLINK 5KVA/5000W MPPT 80A Off-Grid Solar Inverter Power Supply

$913.00
In stock
Add to cart

Specifications

GENERAL

Rated Power
5000VA / 5000W

Communication Interface
Removable USB / RS232 / RS485 / Bluetooth / Dry-contact

Dimension D x W x H (mm)
115 x 300 x 400

Net Weight (kgs)
13

INPUT

Voltage
230VAC

Selectable Voltage Range
170 ~ 280 VAC (For Personal Computers)90 ~ 280 VAC (For Home Appliances)

Frequency Range
50Hz / 60Hz (Auto sensing)

OUTPUT

AC Voltage Regulation (Batt. Mode)
230VAC ± 5%

Surge Power
10000VA

Efficiency (Peak)
90% ~ 93%

Transfer Time
15 ms (For Personal Computers)20 ms (For Home Appliances)

Waveform
Pure sine wave

BATTERY

Battery Voltage
48VDC

Floating Charge Voltage
54VDC

Overcharge Protection
63VDC

SOLAR & AC CHARGER

Solar Charger Type
MPPT

Maximum PV Array Open Circuit Voltage
500VDC

Maximum PV Array Power
5000W

MPP Range @ Operating Voltage
120VDC~450VDC

Maxmum Solar Charge Current
100A

Maximum AC Charge Current
100A
